Product Description

ELECTRICAL DATA
Impedance	50Ω
Frequency Range	Flexible cables DC 11GHz,
Frequency Range	semi-rigd cables DC18GHz
Withstand Voltage	≥2500V,50Hz
Working Voltage	≤1000V,50Hz (sea level)
Insulation Resistance	≥5000mΩ
Contact Resistance	Inner conductor: ≤1.0mΩ
Contact Resistance	Outer conductor: ≤0.2mΩ
RF leakage(2-3GHZ)	Flexible: ≥90dB
3rd order intermodulation	≥140dBc
MECHANICAL DATA
Coupling nut torque	Recommended: 68Ncm--123Ncm /
	6.0 in. lbs--10 in.lbs
	Proof torque: 170 Ncm / 15.0 in.lbs
Proof torque	170Ncm / 15.0 in.lbs
Durability (matings)	≥500
ENVIRONMENTAL DATA
Temperature range	-65°C to +165°C
MATERIAL DATA
Bodies	Brass--Ternary alloy plating
Pin contacts	Brass--Au/Ag plating
Socket contacts	Copper beryllium alloy--Au plating
Crimp ferrules	Brass-- ternary alloy plating
Insulator	PTFE
Gaskets	Silicone rubber
