11kv 3X70mm2 Copper/XLPE/Swa/PVC/PE Underground Cable

Our company has been carrying out Chinese national standard GB 12706 and GB 12666.6(equivalent to IEC 60502 and IEC 60331)for PVC insulated power cable and fire resistant cable needed by domestic customer, and for foreign customers we can manufacture in accordance with BS, DIN and other countries, standards. In addition, we can design and manufacture PVC insulated power cable with special characteristics according to needs of customers.

No.	Description	Unit	Data Offered by Bidder
1	Manufacture		Henan Jinshui Cable Group Co., LTD.
2	Cable name		Medium voltage power cable
3	Standard		IEC 60502
4	Specified voltage	kV	11
5	Conductor material		Copper
6	Conductor size	mm²	70
7	Form of conductor		Circular compacted stranded
8	Numbers*singel wire diameter	Nos./mm	19/2.17
9	Conductor diameter, approx.	mm	10
10	Conductor D.C. resistance at 20ºC	Ω/km	0.276
11	Conductor shield material		Semi-conductive compound
12	Conductor shield material thickness, approx.	mm	0.6
13	Insulation Material		XLPE
14	Insulation Thickness, approx.	mm	3.4
15	Insulation shield material		Semi-conductive compound
16	Insulation shield material thickness, approx.	mm	0.8
17	Metal screen material		Copper tape
18	Copper tape width/thickness	Mm*mm	1x0.1
19	Filler (Non-hygroscopic)		PP
20	Inner Bedding Sheath Material		PVC
21	Inner sheath thickness		1.5
22	Armour		Galvanized steel wire .
23	Armour diameter	Nos./mm	57/2.5
24	Outer sheath material		PE
25	Outer sheath thickness, approx.	mm	2.8
26	Diameter of complete cable, approx.	mm	56
27	Weight	Kg/km	6050
28	Packing length	m	500
29	Packing type		Steel-wooden drum
